注明
额定温度：90?C
额定电压：300/500V
尺度：GB5023
导体:导体使用绞合祼铜或镀锡铜
绝缘:无铅聚氯乙烯
通过VW-1及CUL FT1垂直耐燃连线
环保要求：RoHS & REACH;
利用
通常电源线
参数
| Conductor | Insulation | Maximun Resistance at 20℃ | ||||
| 导体 | 护套 | |||||
| AWG | Core.Number | Nom.Thick. | Average | 20℃最大导体电阻Ω/km | ||
| 线规 | 电缆芯数 | 均匀厚度 | 参考表径 | |||
| mm | mm | |||||
| 0.75 | 2× | 0.80 | 4.75 | 26.00 | ||
| 3× | 5.00 | |||||
| 1.00 | 2× | 0.80 | 5.10 | 19.50 | ||
| 3× | 5.40 | |||||
| 1.50 | 2× | 0.80 | 8.50 | 13.30 | ||
| 3× | 9.00 | |||||
| 2.50 | 2× | 1.10 | 10.00 | 7.98 | ||
| 3× | 10.55 | |||||
